The K10+ is one of our early Morse keyer ICs. It has lots of built in features and wth a K10+ you can contruct a great CW keyer for a low price. The K10+ had two predecessors, the K8 and the K9. Most of the K9 features are carried over to the K10+ with lots of new ones. Note that the K9 and K10+ are not pin compatible. The K10+ is no longer recommended for new designs, the K16 is much better keyer for just a few dollars more. We still sell the K10+ for those who need a replacement or spare.
K10+ Features
- Speed range: 5 - 59 WPM
- HSCW Mode Support
- Message Memory: 96 letters in four slots with embedded commands
- Keying Modes: Straight key, Iambic A or B
- MCW keying mode
- Farnsworth support
- Autospace mode
- Letterspace reduction
- Adjustable dah/dit ratio
- Paddle swap
- Beacon w/Programmable interval
- Sidetone Output
- Adjustable Sidetone frequency
- High true key output
- Optional Speed Pot
- Push-button user interface
- 24 easy to use commands
- Code practice modes
- 3-7 VDC, built in CPU oscillator
- 5 ma active, 1ľA standby
Discontinued, please consider using the K16 or K12 instead. They offer many new features and improvements.
